Manufacture



Iconic Engineering Solutions Ltd now offers CNC manufacturing with its recent purchase, a 3 Axis CNC milling machine. We can machine a wide selection of materials and use high quality tooling to allow us to bring your parts and projects to you in a fast and cost effective way.

Since purchasing the machine we have been servicing the Automotive and Motorsport sector producing complex aluminium components.

We have also invested in several options for offline programming. These include simple DXF file readers which allow us to program complex profiles from a 2D Drawing and a full CAM solution which allows us to program the machine so it can produce complex 3D surfaces and reduce machine cycle times through smart machining strategies.

Camber Adjustment Plate

CAM Simulation of an LMP Car Camber Adjustment Plate. Component was machined from 7075-t6 Aluminium. tricky part on this component was making sure the chamfers on each side of the component were precise so the bearings could be swaged in perfectly.

Suspension Component

CAM Simulation of an LMP Le Mans Car Suspension Component. Manufactured from EN24t steel, this was a tough cookie to cut. Very hard material but the part looked fantastic when complete.

Machining an Enclosure

CNC Machining an aluminium electronics enclosure.

Parts rectification

Components that a customer had made would not fit the mating part so we corrected them.
